APC Smart UPS XL 2200VA 1850W RM 3U Network Package for Server Rooms
SUA2200R3XLNETPKG
NEW & Fresh Stock
30 Day Full Money Back Guarantee! (includes shipping!)
2 Year Warranty
Manufacturer: APC
Model Description: APC Smart UPS XL 2200 2200VA 1850W Serial 120V
Condition: Brand New & Fresh Stock
Part Number: SUA2200R3XLNETPKG
Maximum output: 1850 Watts / 2200 VA
Battery Protected Outlets: 11
Typical backup time at half load: 29.4 minutes (925 Watts)
Typical backup time at full load: 8.2 minutes (1850 Watts)
Output Waveform: Sinewave
Warranty: 2 Year Warranty
Includes: CD with software, Rack Mounting support rails, Smart UPS signaling RS-232 cable, Temperature Probe, USB cable, User Manual, Web/SNMP Management Card
The ExcessUPS Advantage:
1. Always Fresh Stock
2. The Best Warranty in the Industry
3. Unbeatable Customer Service
4. Great Prices
Summary of features of the APC Smart UPS 2200XL RM 3U:
|
Adjustable voltage sensitivity |
|
Adjustable voltage-transfer points |
|
Audible alarms |
|
Automatic restart of loads after UPS shutdown |
|
Automatic self-test |
|
Boost and Trim Automatic Voltage Regulation (AVR) |
|
Cold-start capable |
|
Disconnected battery notification |
|
Field-replaceable power distribution panel |
|
Generator compatible |
|
Global safety approvals |
|
Hot-swappable batteries |
|
InfraStruXure Manager Compatible |
|
Intelligent battery management |
|
LED status indicators |
|
Network manageable |
|
Plug-and-Play external batteries |
|
Plug-and-Play installation |
|
Power conditioning |
|
Predictive failure notification |
|
Pure Sinewave battery backup |
|
Replace Battery LED |
|
Resettable circuit breakers |
|
Safety-agency approved |
|
Scalable runtime |
|
Serial Connectivity |
|
SmartSlot |
|
Temperature-compensated battery charging |
|
USB connectivity |
|
User-replaceable batteries |
APC Smart-UPS XL 2200 SUA2200R3XLNETPKG User's Manual
Detailed specifications for the APC Smart UPS XL 2200VA RM 3U:
Output:
|
Output power capacity |
1850 Watts / 1850 VA |
|
Max Configurable Power |
1980 Watts / 2200 VA |
|
Nominal output voltage |
120V |
|
Output Voltage Distortion |
less than 5% at full load |
|
Output Frequency (sync to mains) |
47-53Hz for 50Hz nominal , 57-63Hz for 60Hz nominal |
|
Crest Factor |
up to 5 : 1 |
|
Waveform type |
Sine wave |
|
Output Connections |
|
(9) NEMA 5-15R |
|
| (2) NEMA 5-20R |
 | |
Input:
|
Nominal input voltage |
120V |
|
Input frequency |
50/60 Hz +/- 3 Hz (auto sensing) |
|
Input Connection Type |
|
NEMA 5-20P |
| |
|
Cord Length |
8 feet (2.44 meters) |
|
Input voltage range for main operations |
82 - 147V |
|
Input voltage adjustable range for mains operation |
75 - 154V |
| Transfer Time |
2-4 ms |
Batteries and Runtime:
|
Battery type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
|
Replacement battery cartridge |
APCRBC105 |
|
RBC™ Quantity |
1 |
|
Typical backup time
at half load |
29.4 minutes (925 Watts) |
|
Typical backup time
at full load |
8.2 minutes (1850 Watts) |
|
Runtime Chart |
Smart-UPS XL |
| Extended Run Options |
|
Communications and Management:
|
Interface port |
DB-9 RS-232,USB,SmartSlot |
|
Pre-Installed SmartSlot™ Cards |
|
|
Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
|
Audible alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
|
Emergency Power Off (EPO) |
Optional |
Surge:
|
Surge energy rating |
800 Joules |
|
Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Physical:
|
Maximum height |
5.25 inches (133 mm) |
|
Maximum width |
19.00 inches (483 mm) |
|
Maximum depth |
26.00 inches (660 mm) |
| Rack Height |
3U |
|
Net weight |
124.00 lbs. (56.36 kg) |
|
Shipping Weight |
139.00 lbs. (63.18 kg) |
|
