APC SMART-UPS 700 Rackmount 3U 700VA 450W SU700RM
Refurbished with New Batteries
At ExcessUPS we specialize in APC power protection products. We professionally refurbish and thoroughly test each and every APC UPS. Every refurbished APC battery backup UPS has brand new high quality batteries installed that meet or exceed APC’s specifications. We install only high quality long life batteries in every uninterruptible power supply, providing reliable and dependable power protection.
APC Smart-UPS 700 Rackmount 3U SU700RM User's Manual
A serial communications cable (940-0024C) is included with this item. It will give you greater control and customization options for this UPS. APC's PowerChute software, available free of charge on APC's website, provides extended features and abilities to enhance the effectiveness and usefulness of this UPS.
APC PowerChute Business Edition Basic v 7.0.5
Output
|
Output power capacity |
700 VA |
|
Output power capacity |
450 Watts |
|
Max Configurable Power |
700 VA |
|
Max Configurable Power |
450 Watts |
|
Nominal output voltage |
120V |
|
Output Voltage Distortion |
Less than 5% at full load |
|
Output Frequency (sync to mains) |
47-53Hz for 50Hz nominal , 57-63Hz for 60Hz nominal |
|
Crest Factor |
up to 5 : 1 |
|
Waveform type |
Sine wave |
|
Output Connections |
|
(6) NEMA 5-15R |
| |
Input
|
Nominal input voltage |
120V |
|
Input frequency |
50/60 Hz +/- 3 Hz (auto sensing) |
|
Input Connection Type |
|
NEMA 5-15P |
| |
|
Cord Length |
6 feet ( 1.83 meters ) |
|
Input voltage range for main operations |
92 - 147 V |
|
Input voltage adjustable range for mains operation |
86 - 154 V |
Batteries and Runtime
|
Battery type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
|
Replacement battery cartridge |
APC Smart-UPS 700 rack mount 3U Replacement Battery Pack RBC9 |
|
RBC™ Quantity |
1 |
|
Typical backup time
at half load |
18.6 minutes (225 Watts) |
|
Typical backup time
at full load |
5.8 minutes (450 Watts) |
|
Runtime Chart |
Smart-UPS |
Communications and Management
|
Interface port |
DB-9 RS-232 , SmartSlot |
|
Available Smart Slot Interface Quantity |
1 |
|
Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
|
Audible alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
|
Emergency Power Off (EPO) |
Optional |
Surge
|
Surge energy rating |
320 Joules |
|
Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Physical
|
Maximum height |
132.00 mm |
|
Maximum width |
483.00 mm |
|
Maximum depth |
356.00 mm |
|
Net weight |
18.18 KG |
|
Shipping Weight |
24.0 KG |
|
