APC SMART-UPS 1000
1000VA 670W
SUA1000
Refurbished with New Batteries
Manufacturer: APC
Model: APC Smart-UPS 1000VA USB & Serial 120V
Condition: Refurbished with Brand New Batteries
Part Number: SUA1000
Maximum output: 670 Watts / 1000 VA
Battery Protected Outlets: 8
Typical backup time at half load: 20.6 minutes (335 Watts)
Typical backup time at full load: 6.1 minutes (670 Watts)
Warranty: 1 Year Full Replacement Warranty
The APC Smart-UPS 1000 SUA1000 protects all of your critical equipment by supplying the ultimate level of reliable, network-grade power protection. The award winning APC Smart-UPS 1000 is an all around, ideal UPS for protecting anything from your home network to critical business servers. With a maximum power output of 670 watts, the SUA1000 offers a very generous runtime. Our refurbished APC UPS Battery Backups all undergo rigorous testing to ensure that the highest level of quality is always provided. Our high standards are strongly reflected in our 1-Year Complete Coverage Warranty included with every UPS and battery purchase.
APC Smart-UPS 1000 SUA1000 User's Manual
A serial communications cable (940-0024C) is included with this item. It will give you greater control and customization options for this UPS. APC's PowerChute software, available free of charge on APC's website, provides extended features and abilities to enhance the effectiveness and usefulness of this UPS.
APC PowerChute Business Edition Basic v 7.0.5
A brief summary of features for the APC Smart-UPS 1000 1000VA SUA1000 UPS:
- Adjustable voltage sensitivity
- Adjustable voltage-transfer points
- Audible alarms
- Automatic restart of loads after UPS shutdown
- Automatic self-test
- Boost and Trim Automatic Voltage Regulation (AVR)
- Cold-start capable
- Disconnected battery notification
- Front-access servicing
- Generator compatible
- Hot-swappable batteries
- InfraStruXure Manager compatible
- Intelligent battery management
- LED status indicators
- Network manageable
- Power conditioning
- Predictive failure notification
- Resettable circuit breakers
- Safety-agency approved
- Serial Connectivity
- SmartSlot
- Temperature-compensated battery charging
- USB connectivity
- User-replaceable batteries
Detailed Technical Specifications:
Output:
|
Output power capacity |
670 Watts / 1000VA |
|
Max Configurable Power |
670 Watts / 1000 VA |
|
Nominal output voltage |
120V |
|
Output Voltage Distortion |
less than 5% at full load |
|
Output Frequency (sync to mains) |
47-53Hz for 50Hz nominal , 57-63Hz for 60Hz nominal |
|
Crest Factor |
up to 5 : 1 |
|
Waveform type |
Sinewave |
|
Output Connections |
|
(8) NEMA 5-15R |
| |
Input:
|
Nominal input voltage |
120V |
|
Input frequency |
50/60 Hz +/- 3 Hz (auto sensing) |
|
Input Connection Type |
|
NEMA 5-15P |
| |
|
Cord Length |
2 Meters |
|
Input voltage range for main operations |
82 - 144 V |
|
Input voltage adjustable range for mains operation |
75 - 154 V |
Batteries and Runtime:
|
Battery type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
|
Replacement battery cartridge |
APC Smart-UPS 1000 SUA1000 1000VA RBC replacement battery pack RBC6 |
|
RBC™ Quantity |
1 |
|
Typical backup time at half load |
20.6 minutes (335 Watts) |
|
Typical backup time at full load |
6.1 minutes (670 Watts) |
|
Runtime Chart |
Smart-UPS |
Communications and Management:
|
Interface port |
DB-9 RS-232 , SmartSlot , USB |
|
Available Smart Slot Interface Quantity |
1 |
|
Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
|
Audible alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
|
Emergency Power Off (EPO) |
Optional |
Surge:
|
Surge energy rating |
459 Joules |
|
Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Physical:
|
Maximum height |
9 inches ( 21.59 cm ) |
|
Maximum width |
7 inches ( 17.02 cm ) |
|
Maximum depth |
17 inches ( 43.94 cm ) |
|
Net weight |
47 lbs. |
|
Shipping Weight |
55 lbs. |
|
Shipping Height |
15 inches ( 38.10 cm ) |
