APC MATRIX 5000 MX5000 208V

APC MATRIX 5000 MX5000
New Batteries
1 Year Warranty
Availability: In stock



APC MATRIX 5000 5KVA 5000VA MX5000 208V
with 2 APC SMARTCELL Battery Packs
Refurbished, with Brand New Batteries


The APC Matrix 5000 has been professionally tested and refurbished. This APC Matrix 5000 comes with 2 SmartCells with brand new batteries installed. The unit is in excellent condition with minor scratches from storage and movement. The unit is 100% functional and comes with a 1 year warranty.

The APC Matrix 5000 has an input of 208V NEMA L6-30P and needs a dedicated 208V 30A power line. Please speak with your site manager or electrician to ensure that you have this power available to you.

The APC Matrix 5000 has a digital display with many options to allow for easy and convenient configuration. The APC Matrix can also be configured using APC's PowerChute Business Edition, available free of charge online at

The APC Matrix 5000 is an excellent industrial unit, a work horse providing 3750W / 5000VA of power. The Matrix 5000 comes standard with two SmartCell Battery Packs. If more runtime is needed, up to 10 SmartCells can be attached in a cascading order to the Matrix. If even more runtime is required a SmartCell XR battery pack can be purchased which contains huge batteries and offers a significantly longer runtime.

Typical runtime with two APC SmartCells:

Typical backup time
at half load

27.8 minutes (1875 Watts)

Typical backup time
at full load

10.2 minutes (3750 Watts)

If you need a custom configuration of the APC Matrix 5000 with more battery packs please contact us.

The APC Matrix 5000 with two SmartCells weighs over 350lbs, this item has to be shipped on a pallet by a freight company. This item can not be shipped by FedEx Ground. To place an order for this item, please call us toll free at 1-866-311-1945. We can make shipping arrangements or buyer can make their own shipping arrangements. Give us a call anytime and we will work out an excellent price effective arrangement.

APC Matrix 5000 MX5000 User's Manual

APC Matrix 5000 MX5000 Features:

  • Adjustable voltage-transfer points
  • Audible alarms
  • Automatic internal bypass
  • Automatic restart of loads after UPS shutdown
  • Automatic self-test
  • Battery modules connected in parallel
  • Boost and Trim Automatic Voltage Regulation (AVR)
  • Field-replaceable power distribution panel
  • Hot-swappable batteries
  • Hot-swappable modules
  • InfraStruXure Manager compatible
  • Intelligent battery management
  • LCD display
  • Manageable external batteries
  • Modular design
  • Plug-and-Play external batteries
  • Power conditioning
  • Predictive failure notification
  • Scalable runtime
  • Serial Connectivity
  • SmartSlot
  • User-replaceable batteries
  • User-replaceable power modules



Output power capacity

3750 Watts / 5000 VA

Max Configurable Power

3750 Watts / 5000 VA

Nominal output voltage


Efficiency at Full Load


Output Voltage Distortion

less than 5% at full load

Output Frequency (sync to mains)

57 - 63 Hz for 60 Hz nominal

Crest Factor

up to 5 : 1

Waveform type


Output Connections

(6) NEMA 5-15R

(1) NEMA L14-30R
(2) NEMA L6-30R



Internal Bypass (Automatic and Manual)

Nominal input voltage


Input frequency

60 Hz +/- 5 Hz
Input Connection Type


Cord Length

6 feet ( 1.83 meters )

Input voltage range for main operations

156 - 252 (208) / 176 - 282 ( 240V)V

Batteries and Runtime:

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Replacement battery cartridge

The MX5000 ships with 2-SmartCell's. There is no RBC available for a standard SmartCell.

RBC™ Quantity


Typical backup time
at half load

27.8 minutes (1875 Watts)

Typical backup time
at full load

10.2 minutes (3750 Watts)

Runtime Chart


Communications and Management:

Interface port

DB-9 RS-232,SmartSlot

Available Smart Slot Interface Quantity


Control panel

Multi-function LCD status and control console

Audible alarm

Alarm when on battery : distinctive low battery alarm : configurable delays

Emergency Power Off (EPO)



Maximum height

683.00 mm

Maximum width

351.00 mm

Maximum depth

452.00 mm

Net weight

137.73 KG

Shipping Weight

160.00 KG

Color Beige

Additional Info

Additional Info

Manufacturer No
Form Factor N/A
Waveform in Battery Mode N/A
Input Voltage N/A
Output (VA) No
Output Voltage N/A
PDU Total Outlets N/A
