Tripp Lite PDUMV30HV 5500W Metered PDU, 30A 208/230V, Output:(6)C19 & (24)C13) - Refurbished
Tripp Lite 5.5kW Metered PDU, 208/230V, (6) C19, (24) C13), L6-30P, 10ft Cord, 0U Vertical
Model: PDUMV30HV
Input: NEMA L6-30P 208V/230V
Output: (24) C13, (6) C19
Refurbished PDU
1 Year Warranty Included
$239.99
Back Order
Manufacturer: Tripp Lite
Model: PDUMV30HV
Description: 5.5kW Single-Phase Metered PDU, 208/230V Outlets (6-C19 & 24-C13), L6-30P, 10ft Cord, Zero U
Input: NEMA L6-30P - 208V, 230V - 30A
Output: (6) C19, (24) C13
Condition: New
Warranty: 1 Year Full Replacement Warranty, additional warranty available
Tripp Lite PDUMV30HV Specifications:
Input
|
Input Phase |
Single-Phase |
|
PDU Input Voltage |
208; 230 |
|
Recommended Electrical Service |
30A 208/230V service |
|
Maximum Input Amps |
24 |
|
Maximum Input Amps Details |
Agency de-rated to 24A continuous |
|
PDU Plug Type |
NEMA L6-30P |
|
Input Cord Length (ft.) |
10 |
|
Input Cord Length (m) |
3.05 |
Output
|
Output Capacity (kW) |
5500 |
|
Output Capacity Details |
5.5kW (230V), 5kW (208V) total capacity / 30A max (Agency de-rated to 24A),15A max per breakered outlet bank; 12A max per C13 outlet |
|
Frequency Compatibility |
50 / 60 Hz |
|
Output Receptacles |
(24) C13; (6) C19 |
|
Output Nominal Voltage |
208/230V |
|
Overload Protection |
Two 15A breakers protect 15 outlets each |
User Interface, Alerts & Controls
|
Front Panel LCD Display |
Set of 2 digital current meters continuously report PDU output current in amps for Bank 1 (15A max) and Bank 2 (15A max) outlets |
|
Front Panel LEDs |
Includes 2 built-in 2-character LED meters to display power consumption of items plugged into each separately breakered 15A loading bank. |
Surge / Noise Suppression
|
Automatic Shut-Off |
No |
Physical
|
Material of Construction |
Aluminum |
|
Form Factors Supported |
0U vertical installation in equipment racks, plus under-counter and wallmount |
|
PDU Form Factor |
Vertical (0U) |
|
Shipping Dimensions (hwd / in.) |
5.00 x 3.00 x 65.00 |
|
Shipping Dimensions (hwd / cm) |
12.70 x 7.62 x 165.10 |
|
Shipping Weight (lbs.) |
11.40 |
|
Shipping Weight (kg) |
5.17 |
|
Unit Dimensions (hwd / in.) |
63.750 x 3.500 x 2.250 |
|
Unit Dimensions (hwd / cm) |
162 x 5.7 x 9.5 |
|
Unit Weight (lbs.) |
8.00 |
|
Unit Weight (kg) |
3.63 |
Environmental
|
Operating Temperature Range |
32° to 104°F (0° to 40°C) |
|
Storage Temperature Range |
-22° to 122°F (-30° to 50°C) |
|
Relative Humidity |
0% to 95% non-condensing |
|
Operating Elevation (ft.) |
0-10,000 |
|
Operating Elevation (m) |
0-10,000 |
